Engineered Framework And High-Strength Materials
YAGO’s steel structure warehouse adopts a pre-engineered system featuring H-section Q345 main frames, galvanized Z/C purlins, and Q235 bracing components. All beams, columns, and joints are modeled with PKPM structural software to meet international standards for load-bearing, wind, and seismic performance. Roofs and walls can be fitted with EPS, glass fiber, rock wool, or PU sandwich panels for thermal insulation. The design supports integrated accessories such as power-free ventilators, skylights, and drainage systems, providing durability and comfort under heavy-duty operations.
Comprehensive System Integration
This prefabricated steel structure incorporates modular bracing, anchoring, and roofing systems that enhance strength and stability. Electric rolling doors, insulated entry doors, and PVC downpipes complete the structure’s function. Each building is corrosion-protected with alkyd painting and powder-coated finishes, ensuring long-term resistance to moisture and oxidation. YAGO’s engineering team customizes every layout based on client parameters—location, wind load, snow load, and crane capacity—offering tailored solutions for industrial and commercial projects.
Large Span And Space Optimization
YAGO’s steel structure buildings are designed to create vast column-free interiors, maximizing usable floor space for storage, manufacturing, or logistics operations. The modular design allows efficient assembly and disassembly, supporting flexible scaling or relocation. Whether for warehouses, aircraft hangars, or multi-story business complexes, this system offers robust performance and architectural versatility backed by industrial-grade materials and precision engineering.
Steel Structure Warehouse
YAGO steel structure is Pre-engineered building system, Main frame is H-Beam, which will calculated by PKPM design software
design requirements, we have full engineers team to make the design and engineering.
1.1 Main components of steel structure building
Item Remark
Main Steel Structure
Steel columns and beams H section steel, Q345 Steel, alkyd painting
Roof purlin Q235 Steel, Z or C section steel. Galvanized
Wall purlin Q235 Steel, Z or C section steel. Galvanized
Bolts Anchor Bolts, Intensive Bolts, OrdinaryBolts.
Bracing System
Cross brace Round steel barsize:Ø20steel grade:Q235 PRE-galvanized
Knee brace L50*4 angle steel Q235, process and alkyd painting
Column bracing ø20round steel bar, steel Q235, process and PRE- galvanized
Tie Rod ø89*3.0, steel Q235, process and alkyd painting
Batter brace ø32*2,ø12round steel bar, steel Q235, process and PREgalvanized
Wall and roof System
Roof panel sheet EPS sandwich panel , glass fiber sandwich panel, rock wool sandwich panel , and PU sandwich panel or steel
Ventilator without power ventilator without power(If require)
Roof daylighting If Require
Wall Panel sheet EPS sandwich panel , glass fiber sandwich panel , rock wool sandwich panel , and PU sandwich panel or steel
Edge cover, Fittings & accessories Galvanized Powder Coated color steel Sheet, angle Alu.Nails, glue etc.
Gutter and Down Pipe
Gutter Gutter:galvanized Color steel
Rainspout pipes ø110 PVC pipe
Door&Windows System
Big door Electric Rolling door Or Sliding door
Single open door Insulated Steel door
1.2 Application for Steel Structure building
1. Logistic Warehouse
2. Industrial Factory
3. Production Workshop
4. Low and high-rise buildings commercial building for office, hotel, apartment, Shopping Mall
5. Aircraft Hangar
6. Chicken Farm Building
1.3 Request for proposal: Please provide the following information for a proposal:
For the steel structure building project, may we know do you have you design and requirement? If not, Our Engineer team will design the steel
structure building for you. If you give the following information, we will give you an satisfactory drawing and proposal.
1. Location (Where will be built):
2. Size ( length* width* height ):
3. Wind Load( Max Wind speed):
4. Snow load:
5. Rain load:
6. Anti-earthquake:
7. Brickwall need or not? If yes, 1.2m high or 1.5m high?
8. Wall and roof materials: Thermal insulation: If yes, fiberglass wool, rock wool, PU sandwich panels will be suggested; if not, the GI corrugated
steels will be ok. The cost of the latter will be much lower than Sandwich panel.
9. Door quantity & size:9. Door quantity & size:_(width)m_(height)m
10. Window quantity & size:_units_(width)m_(height)m
11. Crane needed or not: If yes,_units, crane max lift height_m, max lift capacity_tons, max wheel pressure and min wheel pressure!
May I know your destination port ?So we could add the freight cost into our price and send the CIF proposal to you then.
Looking forward to your reply!
Best Regards
Qingdao Yago Junchi Industry Co.,Ltd.
Ashley Liu
Tel: +86 532 88755689
Mobile&whatsapp: +86 13665329664
Email: sales@yagoindustry.com
About Us
YAGO Industry Co., Ltd., based in Qingdao, China, is a leading steel structure manufacturer with over 15 years of engineering expertise. The company specializes in steel structure buildings, prefabricated houses, and container systems, integrating design, fabrication, and installation into a complete service chain. All projects are engineered using PKPM software and fabricated with automated production lines to ensure precision and reliability. YAGO’s structures are widely used in logistics, mining, oil, agriculture, and construction industries across more than 90 countries. As a certified steel structure building contractor, YAGO delivers custom-engineered solutions that balance cost efficiency, durability, and aesthetic appeal for global clients.
Request your engineered steel structure warehouse design and quotation from YAGO today!
FAQ
What materials are used in YAGO’s steel structure warehouse?
Main frames use Q345 H-section steel, with Q235 galvanized Z/C purlins and insulated sandwich panels.
Can the building design be customized?
Yes, the steel structure manufacturer tailors size, layout, and load capacity according to your project’s specifications.
How fast can a warehouse be installed?
A prefabricated steel structure warehouse can typically be assembled within weeks depending on size and site conditions.
Does YAGO provide design and engineering support?
Yes, full engineering drawings, 3D models, and PKPM load analysis are provided before fabrication.
Is the building suitable for crane systems and heavy equipment?
Yes, YAGO’s steel structure buildings can integrate overhead cranes and reinforced floor systems for industrial use.
